Quattroflow QF5kSU Max. Flow Rate 6,000 lph

Disposable pump chamber
Increased max. flow rate of 6,000 lph with most drives
Self-draining design to minimize non-recoverable product
Enhanced venting to reduce the minimum flow rate required to remove entrapped air during priming
Up to 120:1 turndown ratio
Improved linear flow performance
High flow stability across the entire flow range

Technical Data

Description			Unit	QF5k-SU	QF5kHT-SU	QF5kQCON-SU	QF5kCD-SU
Flow Rate	Eccentric Shaft 5°	Min.	lph	200	50
Flow Rate	Eccentric Shaft 5°	Max.	lph	6,000			5,000
Pumping Pressure	Media Temperature <40°C	Max.	bar	4
Pumping Pressure	Media Temperature <40°C	Continuous	bar	4
Pumping Pressure	Media Temperature >40°C	Max.	bar	4
Pumping Pressure	Media Temperature >40°C	Continuous	bar	4
Pumping Pressure	Neg. Inlet Pressure	Continuous	bar	-0.2
Temperature		Min.	°C (°F)	4 (39)
Temperature		Max.	°C (°F)	60 (140)
Pump Speed		Min.	rpm	30	13
Pump Speed		Max.	rpm	1,200			1,050
Displacement Volume	Eccentric Shaft 5°		ml/rev	91
Connection Specification	Size		Inch	1.5" (TriClamp)
Dimensions	Pump Unit	Length	mm	870	851	950	320
Dimensions	Pump Unit	Width	mm	250	275	275	320
Dimensions	Pump Unit	Height	mm	333	385	404.5	440
Pump Weight with Motor and Housing	Pump Unit		kg	85	100	105	60
IP-Protection Class (Total Pump)	Pump Unit		---	55	54	54	55
Filling Volume	Without Connection		ml	788
Surface	Product Wetted		cm²	1,586
Media	Temperature	Max.	°C (°F)	60 (140)
Sterilization	Autoclave	Max.	°C (°F)	130 (266)
Sterilization	Gamma Irradiation	Max.	kGy	50
Material	Product Wetted	Pump Housing	---	PP
Material	Product Wetted	Valve Plate	---	PP
Material	Product Wetted	Diaphragm	---	TPE
Material	Product Wetted	Valves	---	EPDM
Material	Product Wetted	O-rings	---	EPDM
